Description
Dimension B1(mm): 86;
Dimension B2(mm): 18;
Dimension d2(mm): 120;
Bore diameter of the shaft hole d1 (mm): 80;
Purpose: To fix the shaft;
Type: Adapter;
Type: H;
Suitable for: Sleeve A2318X;
Compliant with RoHS Directive (corresponding to 10 substances);
Suitable for: bearings UK218, UKP218, UKF218;
The nut to be used: AN18;
The washer to be used: AW18X
